基本參數指標：通道尺寸 500（寬）×300（高）mm傳送帶速度 0.22m/s(可調)傳送帶額定負荷 150 kg分辨力 直徑0.101 mm金屬線（直徑0.0787 mm金屬線）（直徑0.078 mm金屬線）穿透力 10 mm鋼板（38 mm鋼板）（40 mm鋼板）膠卷安全性 對ISO1600膠卷安全泄漏劑量 <0.05μGy/hX射線發生器：射線束方向
通道尺寸 500（寬）×300（高）mm
Basic parameter indicators:
Channel size 500(W)×300(H)mm
Conveyor speed 0.22m/s (adjustable)
Conveyor rated load 150 kg
Resolution 0.101 mm diameter metal wire (0.0787 mm diameter metal wire) (0.078 mm diameter metal wire)
Penetration force 10 mm steel plate (38 mm steel plate) (40 mm steel plate)
Film safety Safe for ISO1600 film
Leakage dose <0.05μGy/h
射線束方向 底照式
X-Ray Generator:
Ray beam direction Undershot type
Tube current 0.4~0.5mA (adjustable) (0.6~0.8mA adjustable) (0.4~0.5mA adjustable)
Tube voltage 80 KV (adjustable) (125 KV adjustable) (160 KV adjustable)
Ray beam divergence angle 60°
Cooling / duty cycle Sealed oil cooling / 100%
X射線傳感器 L形光電二極管陣列探測器 (單能量)(多能量)，12bit深度
Image processing system:
X-ray sensor L-shaped photodiode array detector (single energy) (multi-energy), 12bit depth
Display high-resolution 17-inch LCD monitor
Color image display 24-bit true color display
Edge enhancement Object contour edges more clearly
Super Image Enhancement Sharper image details
High-penetration display Improves contrast in bright areas of the image, making easy-to-penetrate areas clearer
Low-transmission display Improves contrast in dark areas of the image, making difficult-to-penetrate areas clearer
Magnifier local magnification function
Brightening/darkening Increasing the brightness of the image/darkening the brightness of the image
Image pull back/forward Display of the first 20 images and any image processing can be performed on the current image
Image recovery Restore the image display to its original state
Image storage Save any image in real time and perform any image processing, continuous working storage
工作溫度／濕度 0℃～45℃／20%～95% (不冷凝)
噪聲級 <60dB
Operating environment:
Operating temperature / humidity 0℃～45℃／20%～95% (non-condensing)
Storage temperature / humidity -20℃～60℃／20%～95% (non-condensing)
Operating voltage 220VAC(±10%)? 50±3HZ
Power loss 1.0KW (maximum)
Noise level <60dB
